Valleylab ForceTriad Electrosurgical Unit – Advanced Vessel Sealing, Monopolar & Bipolar Surgical Platform

The Valleylab ForceTriad is a cutting-edge energy platform designed for precise control in monopolar, bipolar, and advanced LigaSure™ vessel sealing procedures. Trusted in operating rooms worldwide, it provides seamless energy delivery across multiple surgical modalities—enabling surgeons to perform with greater safety, speed, and confidence.

Its intuitive touchscreen interface, advanced power management, and compatibility with LigaSure™ technology make it an ideal system for open surgery, laparoscopy, and specialty procedures such as ENT, urology, gynecology, and thoracic surgery.

⚙️ Technical Specifications:

🔌 Electrical Requirements:

• Input Voltage: 100–240V AC, 50/60 Hz

• Power Consumption: Up to 900 VA

⚡ Output Power Modes:

🔸 Monopolar Cut:

• Max Power: 300 W

• Modes: Pure, Blend 1, Blend 2, Blend 3

• Tissue Feedback Control: Yes

🔸 Monopolar Coagulation:

• Max Power: 120 W

• Modes: Spray, Fulgurate, Desiccate

🔸 Bipolar:

• Max Power: 150 W

• Modes: Standard, Macro, Precise

🔸 LigaSure™ Vessel Sealing:

• Seal Mode: Advanced tissue sensing

• Seal Time: ~2 seconds

• Seal Vessels Up To: 7 mm

🌡️ Environmental Operating Range:

• Temperature: 10°C to 40°C

• Humidity: 30–75% (non-condensing)

• Atmospheric Pressure: 700 to 1060 mbar

🧠 Key Features:

• All-in-one platform: monopolar, bipolar, and LigaSure™

• Smart tissue sensing for real-time power adjustment

• Touchscreen control panel with user-friendly UI

• Compatible with a wide range of handpieces and return electrodes

• Optional footswitch control

• LigaSure technology for fast, secure vessel sealing

• Integrated system diagnostics for safer operation

📐 Dimensions & Weight:

• Size (H × W × D): 221 mm × 444 mm × 533 mm

• Weight: Approx. 11.5 kg

🏥 Clinical Applications:

• General Surgery

• Laparoscopy

• Vascular Surgery

• Gynecology & Urology

• ENT & Thoracic Procedures
