Valleylab Force 2 Electrosurgical Unit (ESU) – Monopolar & Bipolar Energy for Surgical Precision

The Valleylab Force 2 Electrosurgical Unit is a high-performance, solid-state generator providing monopolar and bipolar outputs with automatic power compensation. It features three cutting modes and three coagulation modes, making it suitable for a wide variety of surgical procedures.

Known for its quiet operation, reliable performance, and minimal arcing, the Force 2 is a staple in operating rooms globally. It offers instant response feedback for tissue impedance changes, helping improve precision and reduce thermal injury.

⚙️ Technical Specifications:

🔌 Power & Electrical Requirements:

• Input Voltage: 100–120V or 220–240V AC

• Frequency: 50/60 Hz

• Power Consumption: 440 VA max

⚡ Output Power Ratings:

🔸 Monopolar Cut Modes:

• Pure Cut: Up to 300 W @ 300 Ω

• Blend 1: Up to 250 W

• Blend 2: Up to 200 W

🔸 Monopolar Coag Modes:

• Desiccate (Low-Voltage): Up to 120 W @ 500 Ω

• Fulgurate (High-Voltage): Up to 120 W @ 500 Ω

• Spray Coag: Up to 120 W @ 500 Ω

🔸 Bipolar Mode:

• Coagulation: Up to 70 W @ 100 Ω

🌡️ Environmental Conditions:

• Operating Temperature: 10°C – 40°C (50°F – 104°F)

• Humidity: 30% – 75% (non-condensing)

• Atmospheric Pressure: 700 to 1060 mbar

🧠 Features:

• Three cutting modes: Pure Cut, Blend 1, Blend 2

• Three coagulation modes: Spray, Desiccate, Fulgurate

• Bipolar output for precision coagulation

• Audible tone indicator & visual LED display for safety feedback

• Closed-loop power regulation – real-time tissue sensing

• Compact and rugged design

📐 Physical Dimensions:

• Size (H × W × D): 127 mm × 355 mm × 457 mm

• Weight: Approx. 9.5 kg

🏥 Applications:

• General Surgery

• Laparoscopy

• Gynaecology

• Urology

• ENT Procedures
