3.5mm Small DCP Plate – Dynamic Compression Plate (Stainless Steel/ Titanium)

The 3.5mm Small Dynamic Compression Plate (DCP) is a highly reliable orthopedic implant designed for internal fixation of fractures in small bones, particularly in the forearm, humerus, or clavicle. Manufactured from high-grade stainless steel or titanium, this plate enables controlled compression across the fracture site, promoting rapid bone healing and stability.

The design incorporates oval-shaped holes that allow for axial compression and interfragmentary compression using standard cortical screws. The small DCP plate is widely used in trauma surgery and offers excellent contouring ability, especially useful in anatomically complex regions.

Whether used in simple diaphyseal fractures or more complex comminuted cases, the 3.5mm Small DCP plate provides optimal support while minimizing soft tissue irritation.

✅ Key Features:

• 🛠️ Dynamic Compression Design: Oval holes allow axial compression using standard 3.5mm cortical screws

• 🔩 Material Options: Available in Stainless Steel (316L) or Titanium Alloy (Ti-6Al-4V)

• 🧩 Hole Configuration: Available from 4 to 12 holes based on surgical requirement

• 🦴 Anatomical Compatibility: Designed for radius, ulna, clavicle, and humerus fractures

• 🔒 Secure Fixation: Designed to be used with 3.5mm cortical screws

• 🩺 Surgical Use: Open reduction and internal fixation (ORIF)

✅ Technical Specifications:

• Plate Thickness: ~3.3 mm

• Hole Diameter: 3.5 mm

• Hole Type: Dynamic compression holes (elongated)

• Hole Spacing: 16 mm (approx., may vary by model)

• Material: Stainless Steel 316L / Titanium

• Length Options: Based on number of holes (4, 6, 8, 10, 12)

✅ Applications:

• Diaphyseal fractures of radius or ulna

• Clavicle fractures

• Humeral shaft fractures

• Periprosthetic fracture stabilization

• Fractures requiring axial compression

📦 Available Variants:

• 3.5mm Small DCP Plate – 4 Holes

• 3.5mm Small DCP Plate – 6 Holes

• 3.5mm Small DCP Plate – 8 Holes

• 3.5mm Small DCP Plate – 10 Holes

• 3.5mm Small DCP Plate – 12 Holes

(Custom sizes available upon request)
